Name: Enhanced Flow Path

Display Field: Value

Type: Raster Layer

Geometry Type: null

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="margin:0 0 11 0;"><SPAN>The </SPAN><A href="https://chesapeakeconservancy.org/conservation-innovation-center/high-resolution-data/enhanced-flow-paths/"><SPAN>enhanced flow path dataset</SPAN></A><SPAN> (water network) created from using the Chesapeake Conservancy's </SPAN><A href="https://chesapeakeconservancy.org/wp-content/uploads/2018/07/CIC_Enhanced_Flowpath_Methods_20180703.pdf"><SPAN>flow path analysis methodology</SPAN></A><SPAN>, combining terrain/elevation data and the Chesapeake Conservancy’s high resolution land cover.</SPAN></P><P STYLE="margin:0 0 0 0;"><SPAN>The Lidar-derived digital elevation model (Statewide DCNR PAMAP 2006-2008 - Quality Level 3 LiDAR - 1 meter DEM) was hydro-conditioned (breached and filled) using the open-source software SAGA and ArcGIS Hydrology toolbox. Flow direction and Flow accumulation rasters were calculated to delineate flow paths. An accumulation threshold of 60 acres of upslope land was applied to identify a given pixel as a channel head; anything downstream of that channel head is identified as a flow path. The flow paths were then widened based on the total upslope area and the USGS regional curve equation for the Coastal Plain region of MD and VA. Large rivers and other open water features classified as “water” in the high resolution land cover dataset were added to the widened flow paths dataset. This final integration is the “enhanced flow path dataset.” Follow the link to see the Chesapeake Conservancy's </SPAN><A href="https://chesapeakeconservancy.org/wp-content/uploads/2018/06/PA-Streams-Accuracy-Assessment.pdf"><SPAN>PA stream mapping accuracy assessment</SPAN></A><SPAN>.</SPAN></P><P><SPAN /></P></DIV></DIV></DIV>

Service Item Id: 6d0d53cea97043fea3c4c78c955a3ea0

Copyright Text: Chesapeake Conservancy, Conservation Innovation Center, Chesapeake Bay Program, University of Vermont Spatial Analysis Laboratory

Default Visibility: true

MaxRecordCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 300000

Max Scale: 0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1987403.3003880987
YMin: 195063.59071519392
XMax: 2224079.615626841
YMax: 398358.1553529071
Spatial Reference: 102729  (2272)

Drawing Info:

N/A

Advanced Query Capabilities:

Supports Statistics: false
Supports OrderBy: false
Supports Distinct: false
Supports Pagination: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: false
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: false
Supports Having Clause: false
Supports Count Distinct: false
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• OID ( type: esriFieldTypeOID, alias: OID )
• Value ( type: esriFieldTypeInteger, alias: Value )
• Count ( type: esriFieldTypeDouble, alias: Count )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
